▶  2 Pins

▶  Rated Current: 80A

▶ Contact Resistance: ≤2mΩ

▶ Insulation Resistance: ≥1500MΩ

▶ Dielectric Withstand Voltage: 1500V AC

▶  Protection Class: IP 67（After mating）

▶ Salt Spray Rating: 720h

▶  Mating Cycles: ≤200cycles

▶  Cable Specification: 6mm^2~16mm^2

▶ Suitable Cable Outer Diameter: ∅13~19mm

▶  Operating Temperature: -40℃ ~ 105℃
