▶  8+21 Pins

▶  Rated Current: 12#:35A，20#: 5A

▶ Contact Resistance: 12#: ≤1mΩ，20#:≤5mΩ

▶ Insulation Resistance: ≥500MΩ DC500V

▶ Dielectric Withstand Voltage: 12#: 1500V AC，20#:500V AC

▶  Mating Cycles: ≤500cycles

▶ Contact Separation Force (Single Pin): 12#:5～10N，20#:0.8～2.0N
